Creating a secure and reliable VPN connection between a Juniper SRX series firewall and a FortiGate device is a common requirement for many organizations. This guide provides a detailed walkthrough of how to configure an IPsec VPN between these two platforms, ensuring secure communication between your networks. So, let's dive in and get this VPN tunnel up and running, folks!

Understanding the Basics

Before we get our hands dirty with configurations, let's quickly recap the key components involved in setting up an IPsec VPN. This will help you understand the 'why' behind each step, not just the 'how'.

• IPsec (Internet Protocol Security): A suite of protocols that provides secure communication over IP networks. It achieves this by authenticating and encrypting each IP packet in a data stream.
• VPN (Virtual Private Network): A technology that creates a secure, encrypted connection over a less secure network, such as the internet. In our case, IPsec will provide the security for our VPN.
• IKE (Internet Key Exchange): A protocol used to establish a security association (SA) between two devices. It handles the negotiation of encryption and authentication algorithms.
• Security Association (SA): An agreement between two or more entities on the security services they will use while communicating. This includes things like encryption algorithms, authentication methods, and key exchange parameters.
• Phase 1 (IKE Phase 1): The first phase of the IKE negotiation, where the two devices authenticate each other and establish a secure channel for further communication. This phase focuses on setting up the foundation for the IPsec tunnel.
• Phase 2 (IKE Phase 2): The second phase, where the IPsec SAs are negotiated. This phase determines the specific encryption and authentication methods used to protect the data transmitted through the VPN tunnel. This is where the actual data protection configuration happens.

Why is this important, you ask? Understanding these core concepts will empower you to troubleshoot issues effectively and customize your VPN setup to meet specific security requirements. When you get the fundamentals down, you're not just copy-pasting configurations; you're actually understanding the flow. That makes all the difference when things get a little hairy! Plus, knowing your IKE from your IPsec will make you sound super cool at the next tech meeting.

Step 1: Juniper SRX Configuration

First, let's configure the Juniper SRX device. We'll start by setting up the IKE (Phase 1) proposal, policy, and gateway, followed by the IPsec (Phase 2) proposal and policy. Finally, we'll configure the traffic selector and the security policy to allow traffic through the VPN.

IKE Phase 1 Configuration

This is where we set up the initial secure connection between the SRX and the FortiGate. It's like the handshake before the real conversation begins.

set security ike proposal ike-proposal-fortigate authentication-method pre-shared-keys
set security ike proposal ike-proposal-fortigate dh-group group14
set security ike proposal ike-proposal-fortigate authentication-algorithm sha256
set security ike proposal ike-proposal-fortigate encryption-algorithm aes-256-cbc
set security ike proposal ike-proposal-fortigate lifetime-seconds 28800

set security ike policy ike-policy-fortigate mode main
set security ike policy ike-policy-fortigate proposals ike-proposal-fortigate
set security ike policy ike-policy-fortigate pre-shared-key ascii-text "YOUR_PRE_SHARED_KEY"

set security ike gateway ike-gateway-fortigate ike-policy ike-policy-fortigate
set security ike gateway ike-gateway-fortigate address REMOTE_GATEWAY_IP
set security ike gateway ike-gateway-fortigate external-interface ge-0/0/0 ; replace with your outgoing interface
set security ike gateway ike-gateway-fortigate version v2-only

• ike-proposal-fortigate: Defines the encryption, authentication, and Diffie-Hellman group used for IKE Phase 1.
• ike-policy-fortigate: Specifies the IKE proposal and pre-shared key used for authentication.
• ike-gateway-fortigate: Defines the remote gateway IP address and the external interface used for the VPN.

Important Considerations:

• Pre-Shared Key: Replace YOUR_PRE_SHARED_KEY with a strong, randomly generated key. Keep this key secure!
• External Interface: Ensure that ge-0/0/0 is replaced with the correct interface on your SRX device that connects to the internet.
• Remote Gateway IP: Replace REMOTE_GATEWAY_IP with the public IP address of the FortiGate device.
• DH-Group: Group14 (2048-bit MODP group) is a good balance of security and performance, but you can adjust this based on your security needs and the capabilities of both devices. Make sure both sides match!

IPsec Phase 2 Configuration

Now, let's configure the IPsec settings, which define how the actual data will be encrypted and protected.

set security ipsec proposal ipsec-proposal-fortigate protocol esp
set security ipsec proposal ipsec-proposal-fortigate authentication-algorithm hmac-sha256-128
set security ipsec proposal ipsec-proposal-fortigate encryption-algorithm aes-256-cbc

set security ipsec policy ipsec-policy-fortigate proposals ipsec-proposal-fortigate

set security ipsec vpn ipsec-vpn-fortigate bind-interface st0.0
set security ipsec vpn ipsec-vpn-fortigate ike gateway ike-gateway-fortigate
set security ipsec vpn ipsec-vpn-fortigate ipsec-policy ipsec-policy-fortigate
set security ipsec vpn ipsec-vpn-fortigate traffic-selector ts-local local-address 192.168.1.0/24
set security ipsec vpn ipsec-vpn-fortigate traffic-selector ts-local remote-address 192.168.2.0/24
set security ipsec vpn ipsec-vpn-fortigate traffic-selector ts-local local-port any
set security ipsec vpn ipsec-vpn-fortigate traffic-selector ts-local remote-port any

set interfaces st0 unit 0 family inet address 10.1.1.1/30

• ipsec-proposal-fortigate: Defines the ESP protocol, authentication algorithm, and encryption algorithm for IPsec Phase 2.
• ipsec-policy-fortigate: Specifies the IPsec proposal to be used.
• ipsec-vpn-fortigate: Creates the VPN tunnel and associates it with the IKE gateway and IPsec policy.
• traffic-selector ts-local: Defines the local and remote networks that will be allowed to pass through the VPN.
• interfaces st0 unit 0: Configures the st0 interface, which is the tunnel interface for the VPN. The IP address 10.1.1.1/30 is an example; you should use an appropriate IP address range for your network.

Key Points:

• ESP Protocol: ESP (Encapsulating Security Payload) provides encryption, authentication, and integrity.
• Traffic Selectors: The local-address and remote-address should match the networks you want to connect. For example, if your local network is 192.168.1.0/24 and the remote network behind the FortiGate is 192.168.2.0/24, you'll use those values.
• ST0 Interface: The st0 interface is a virtual tunnel interface. You'll need to assign an IP address to it. This IP address should be in a different subnet than your local and remote networks. A /30 subnet is typically used for point-to-point VPN connections.

Security Policy Configuration

Finally, we need to create a security policy to allow traffic to flow through the VPN tunnel.

set security policies from-zone trust to-zone untrust policy vpn-policy-fortigate match source-address 192.168.1.0/24
set security policies from-zone trust to-zone untrust policy vpn-policy-fortigate match destination-address 192.168.2.0/24
set security policies from-zone trust to-zone untrust policy vpn-policy-fortigate match application any
set security policies from-zone trust to-zone untrust policy vpn-policy-fortigate then permit tunnel ipsec-vpn ipsec-vpn-fortigate

set security policies from-zone untrust to-zone trust policy vpn-policy-return match source-address 192.168.2.0/24
set security policies from-zone untrust to-zone trust policy vpn-policy-return match destination-address 192.168.1.0/24
set security policies from-zone untrust to-zone trust policy vpn-policy-return match application any
set security policies from-zone untrust to-zone trust policy vpn-policy-return then permit tunnel ipsec-vpn ipsec-vpn-fortigate

• from-zone trust to-zone untrust: Defines the policy for traffic originating from the trust zone (your internal network) and destined for the untrust zone (the remote network behind the FortiGate).
• from-zone untrust to-zone trust: Defines the policy for return traffic, originating from the untrust zone and destined for the trust zone.
• match source-address and match destination-address: Specifies the source and destination networks for the policy.
• then permit tunnel ipsec-vpn ipsec-vpn-fortigate: Allows the traffic to pass through the specified IPsec VPN tunnel.

Don't Forget:

• Zones: Make sure your zones are correctly configured. The trust and untrust zones are examples; adjust these to match your specific zone configuration.
• Bidirectional Policies: You need policies in both directions to allow traffic to flow both ways through the VPN tunnel.

Step 2: FortiGate Configuration

Now, let's switch gears and configure the FortiGate device. The configuration process is similar to the SRX, but the syntax is different.

IKE Phase 1 Configuration

Log in to your FortiGate's web interface or CLI and follow these steps to configure the IKE Phase 1 settings.

config vpn ipsec phase1-interface
    edit "SRX-VPN"
        set interface "wan1"  ; replace with your outgoing interface
        set ike-version 2
        set keylife 28800
        set proposal aes256-sha256
        set dhgrp 14
        set remote-gw REMOTE_GATEWAY_IP
        set psksecret YOUR_PRE_SHARED_KEY
        set type static
    next
end

• edit "SRX-VPN": Creates a new Phase 1 configuration named "SRX-VPN".
• set interface "wan1": Specifies the outgoing interface used for the VPN.
• set ike-version 2: Sets the IKE version to 2.
• set keylife 28800: Sets the key lifetime to 28800 seconds (8 hours).
• set proposal aes256-sha256: Defines the encryption and authentication algorithms.
• set dhgrp 14: Sets the Diffie-Hellman group to 14.
• set remote-gw REMOTE_GATEWAY_IP: Specifies the remote gateway IP address (the SRX's public IP).
• set psksecret YOUR_PRE_SHARED_KEY: Sets the pre-shared key.
• set type static: Specifies a static VPN configuration.

Important Notes:

• Interface: Replace wan1 with the correct interface on your FortiGate.
• IKE Version: Using IKEv2 is generally recommended for better security and performance.
• Pre-Shared Key: Match the pre-shared key with the SRX configuration.

IPsec Phase 2 Configuration

Next, configure the IPsec Phase 2 settings.

config vpn ipsec phase2-interface
    edit "SRX-VPN-PH2"
        set phase1name "SRX-VPN"
        set proposal aes256-sha256
        set pfs disable
        set auto-negotiate enable
        set src-addr-type subnet
        set dst-addr-type subnet
        set src-subnet 192.168.2.0 255.255.255.0
        set dst-subnet 192.168.1.0 255.255.255.0
    next
end

• edit "SRX-VPN-PH2": Creates a new Phase 2 configuration named "SRX-VPN-PH2".
• set phase1name "SRX-VPN": Associates this Phase 2 configuration with the Phase 1 configuration we created earlier.
• set proposal aes256-sha256: Defines the encryption and authentication algorithms for Phase 2.
• set pfs disable: Disables Perfect Forward Secrecy (PFS). While PFS is generally a good security practice, disabling it can sometimes improve compatibility between different VPN devices. You can enable it if both devices support it and you desire the added security. Make sure the DH-Group also match.
• set auto-negotiate enable: Enables auto-negotiation of IPsec parameters.
• set src-addr-type subnet and set dst-addr-type subnet: Specifies that we are using subnets for the source and destination addresses.
• set src-subnet and set dst-subnet: Defines the source and destination subnets for the VPN.

Key Considerations:

• Phase 1 Name: Ensure that the phase1name matches the name of your Phase 1 configuration.
• Subnets: Double-check that the src-subnet and dst-subnet are correct.
• PFS: Only enable Perfect Forward Secrecy (PFS) if both the FortiGate and the SRX support it and you have verified that it is working correctly.

Policy Configuration

Finally, create the firewall policies to allow traffic to pass through the VPN tunnel.

config firewall policy
    edit 0
        set name "SRX-to-FortiGate"
        set srcintf "lan" ; replace with your internal interface
        set dstintf "SRX-VPN"
        set srcaddr "192.168.2.0/24"
        set dstaddr "192.168.1.0/24"
        set action accept
        set schedule "always"
        set service "ALL"
    next
    edit 1
        set name "FortiGate-to-SRX"
        set srcintf "SRX-VPN"
        set dstintf "lan" ; replace with your internal interface
        set srcaddr "192.168.1.0/24"
        set dstaddr "192.168.2.0/24"
        set action accept
        set schedule "always"
        set service "ALL"
    next
end

• set srcintf and set dstintf: Specifies the source and destination interfaces for the policy. The SRX-VPN interface is automatically created when you configure the IPsec VPN.
• set srcaddr and set dstaddr: Defines the source and destination addresses for the policy.
• set action accept: Allows the traffic to pass through the firewall.
• set service "ALL": Allows all services (ports and protocols) through the VPN. You can restrict this to specific services for better security.

Important Reminders:

• Interfaces: Make sure the interface names are correct. lan is a placeholder; replace it with your actual internal interface.
• Bidirectional Policies: As with the SRX, you need policies in both directions.
• Service: For enhanced security, avoid using set service "ALL". Instead, specify only the services that need to be allowed through the VPN, such as HTTPS, SSH, or custom services.

Step 3: Verification and Troubleshooting

After completing the configurations on both the Juniper SRX and FortiGate devices, it's time to verify that the VPN tunnel is up and running correctly. Here's how you can do it.

Verification

• Juniper SRX:

  • Use the command show security ike sa to check the IKE Phase 1 status. Look for the state to be UP. If it's not up, there may be an issue with the IKE configuration.
  • Use the command show security ipsec sa to check the IPsec Phase 2 status. Verify that the SPIs (Security Parameter Indexes) are established and that the tunnel is active.

• FortiGate:

  • In the FortiGate web interface, go to VPN > IPsec Monitor. This will show you the status of all IPsec tunnels. Look for your "SRX-VPN" tunnel and ensure that it is in the "UP" state.
  • You can also use the CLI command diagnose vpn ike status to check the IKE status and diagnose vpn tunnel list to see a list of all VPN tunnels and their status.

Troubleshooting

If the VPN tunnel is not coming up, here are some common issues and how to troubleshoot them:

• Mismatched Pre-Shared Keys: Double-check that the pre-shared keys are identical on both the SRX and the FortiGate. Even a small typo can prevent the tunnel from establishing.
• Incorrect IP Addresses: Verify that the remote gateway IP addresses are correct on both devices. Ensure that the SRX is pointing to the FortiGate's public IP address and vice versa.
• Firewall Rules: Ensure that there are no firewall rules blocking the IKE (UDP port 500 and 4500) or ESP (IP protocol 50) traffic between the SRX and the FortiGate. The devices need to be able to negotiate the VPN connection.
• Incorrect Traffic Selectors: Double-check that the traffic selectors (local and remote networks) are configured correctly on both devices. If the traffic selectors are not properly defined, the VPN tunnel may come up, but traffic will not flow through it.
• MTU Issues: Sometimes, large packet sizes can cause issues with VPN tunnels. Try adjusting the MTU (Maximum Transmission Unit) size on the tunnel interfaces (st0.0 on the SRX) to a lower value, such as 1400 bytes. Use the command set interface st0.0 mtu 1400 on the SRX.
• NAT Issues: If either the SRX or the FortiGate is behind a NAT device, you may need to configure NAT-T (NAT Traversal) to allow the VPN tunnel to establish correctly. Ensure that NAT-T is enabled on both devices if necessary.
• Log Analysis: Examine the logs on both the SRX and the FortiGate for any error messages or clues about what might be going wrong. The logs can often provide valuable information about the cause of the problem.

Conclusion

Configuring an IPsec VPN between a Juniper SRX and a FortiGate device involves several steps, but by following this guide, you should be able to establish a secure and reliable connection between your networks. Remember to double-check your configurations, verify the tunnel status, and troubleshoot any issues that may arise. Once you have a working VPN tunnel, you can securely transmit data between your networks, protecting your sensitive information from eavesdropping and unauthorized access. If you have any questions, feel free to ask. Good luck!
